税込価格:¥159,500
FEATURE:| MODEL NAME | BEND R2 |
|---|---|
| MODEL CATEGORY | ROAD, TOURING & GRAVEL, URBA N |
| SIZES (CT) | S/M/L |
| COLOR | BLUE BLACK |
| FRAME | ALX GRAVEL W/ FLATMOUNT, CARRIER & FE NDER READY |
| FORK | CARBON W/ FLATMOUNT, CARRIER & FENDER R EADY |
| HANDLEBAR | ENTITY EXPERT ALLOY |
| STEM | ENTITY EXPER T ALLOY |
| HEADSET | ALLOY TAPERED HEADSE T ID:42/52MM |
| SADDLE | ENTITY SADDLE |
| SEATPOST | ENTITY EXPERT 0MM OFFSET |
| CRANKSET | PROWHEEL ALLOY CRA NKSET 46-34T 170MM |
| PEDAL | FPD, NW-487 |
| BOTTOM BRACKET | CARTRIDGE BB |
| CHAIN | KMC X-9 |
| CASSETTE SPROCKET | SHIMANO CSHG200-9 11-3 4T |
| FRONT DERAILLEUR | SHIMANO FD-R300 0 |
| REAR DERAILLEUR | SHIMANO RD-R3000 9 SPE ED |
| SHIFTING LEVER | SHIMANO ST-R3000 2X9 SPEE D |
| BRAKE LEVER | INCLUDE SHIFTER |
| FRONT BRAKE | TEKTRO MD-C40 0 MECHANICAL DISC BRAKE |
| REAR BRAKE | TEKTRO MD-C40 0 MECHANICAL DISC BRAKE |
| ROTOR | TEKTRO TR-160MM |
| TYRE | PERFORMANCE TIRE 6 50BX47 |
| WHEELSET | TUBELESS READY WHEELSET DISC 650B 32H |
| WEIGHT | 13.6 KG (SIZE MEDIUM) |
| A | B | C | D | E | F | G | H | I | J | K | L | M | |
| Size | Seat Tube Length | Seat Tube Angle | Effective Seat Tube Angle | Head Tube Length | Head Tube Angle | Effective Top Tube | BB Height | BB Offset | Chainstay Length | Wheelbase | Frame Reach | Frame Stack | Standover Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 430 | 74 | 74 | 140 | 71 | 528.2 | 261.5 | 80 Drop | 420 | 999 | 365 | 569.1 | 677.4 |
| M | 480 | 74 | 74 | 170 | 71.5 | 551.9 | 261.5 | 80 Drop | 420 | 1019 | 380 | 599.5 | 720.3 |
| L | 535 | 74 | 74 | 200 | 72.5 | 576.2 | 261.5 | 80 Drop | 420 | 1034 | 395 | 632 | 767 |
| 140 | 145 | 150 | 155 | 160 | 165 | 170 | 175 | 180 | 185 | 190 | cm | |
| S | ||||||||||||
| M | ||||||||||||
| L |
※商品仕様、カラーその他は、予告なく変更される可能性があります
