税込価格:¥605,000
FEATURE:| FRAME | ACX PERFORMANCE UCI APPROVED |
|---|---|
| FORK | ACX PERFORMANCE UCI APPROVED, TAPER 1-1/8” TO 1-1/2” |
| HANDLERBAR | FSA ENERG Y COMPACT, W:400MM(XS, S) 420MM(M) BB:31.8MM R/D:123.2MM, B/R:78mMM |
| STEM | FSA NS SMR, EXT:90mm(XS, S) /100mm(M), BB:31 .8MM B/R:6DEG |
| HEADSET | INTEGRATED (IS)SEAL ED BEARING FOR OS H EAD TUBE, IS 52/28.6 | IS 52/40 |
| SADDLE | ENTITY FLUX 2, CR-MO Φ7mm |
| SEATPOST | CARBON AERO 35 x 337mm(XS) /357mm(S, M) |
| CRANKSET | SHIMANO ULTEGRA FC-R8000 52/36T , 170M M(XS, S, M) |
| BOTTOM BRACKET | SHIMANO BB-R S500-PB PRESSFIT BB86 |
| CHAIN | SHIMANO CN-HG6 01-11 |
| CASSETTE SPROCKET | SHIMANO, ULTEGRA CS-R8000 11-30T 11-SPEED |
| REAR DERAILLEUR | SHIMANO, ULTEGRA RD-R8000-SS DIRECT ATTACHMENT |
| SHIFTING LEVER | SHIMANO ST-R8020 2x11-SPEED DC L |
| BRAKE LEVER | SHIMANO ULTEGRA ST-R8020 HYDRAUL IC DISC BRAKE |
| BRAKE | SHIMANO ULTEGRA BR-R8070 HYDRAUL IC DISC BRAKE |
| ROTOR | SHIMANO SM-RT70 F:160MM / R:140MM CENTER LOCK |
| TYRE | SCHWALBE ONE ADDIX T LE 700X28C |
| WHEELSET | ENTITY WR5 CARBON DISC RIMS(50MM) W/ TUBELESS TAPE INSTALLED THRU AXLE 12x100x142mm |
| SIZE (CT) | XS, S, M |
| COLOR | NUBIUM GREY |
| WEIGHT | around 8 KG (S size W /O Pedals) |
| A | B | C | D | E | F | G | H | I | J | K | L | M | |
| Size | Seat Tube Length | Seat Tube Angle | Effective Seat Tube Angle | Head Tube Length | Head Tube Angle | Effective Top Tube | BB Height | BB Offset | Chainstay Length | Wheelbase | Frame Reach | Frame Stack | Standover Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 475 | 74.7 | 74.7 | 115 | 71.8 | 517.3 | 271 | 73(DROP) | 415 | 976 | 375 | 520.2 | 739.4 |
| S | 500 | 74.3 | 74.3 | 130 | 72 | 530.4 | 271 | 73(DROP) | 415 | 984 | 380 | 535.2 | 763.2 |
| M | 520 | 74 | 74 | 145 | 72.3 | 543.0 | 271 | 73(DROP) | 415 | 991 | 385 | 550.4 | 780.8 |
| 140 | 145 | 150 | 155 | 160 | 165 | 170 | 175 | 180 | 185 | 190 | cm | |
| XS | ||||||||||||
| S | ||||||||||||
| M |
※商品仕様、カラーその他は、予告なく変更される可能性があります
