税込価格:¥173,800
FEATURE:| MODEL NAME | TRID |
|---|---|
| MODEL CATEGORY | DIRT JUMP |
| SIZE (CT) | ALL SIZE |
| COLOR | BLACK/CREAM |
| FRAME | AL6 DIRT JUMP, 135MM O.L.D., 100MM TRAVEL, IS MOUNT 160MM |
| FORK | X-FUSION SLANT, 100MM, TA 15MM, TAPPERED |
| HANDLERBAR | ALLOY W:750MM R:38.1MM BB:3.18MM |
| STEM | ALLOY E:40MM R:0DEG BB:31.8MM |
| HEADSET | ZS 44/28.6 | ZS 56/40 |
| SADDLE | POLYGON PIVOTAL SADDLE |
| SEATPOST | ALLOY, PIVOTAL, 30.9X200MM |
| CRANKSET | SAMOX TAF15-D32A 32T, 170MM |
| BOTTOM BRACKET | SAMOX INTEGRATED BB BSA |
| CHAIN | KMC HL-710 |
| CASSETTE SPROCKET | COG 14T |
| BRAKE LEVER | SHIMANO BL-MT201 |
| BRAKE | SHIMANO BR-MT200 |
| FRONT BRAKE | SHIMANO BR-MT200 |
| ROTOR | SHIMANO SM-RT26 160MM |
| TYRE | VEE XCV, 26”X2.25” |
| WHEELSET | WTB SX-25 DISC 26” |
| WEIGHT | 12.8 KG |
| A | B | C | D | E | F | G | H | I | J | K | L | M | |
| Size | Seat Tube Length | Seat Tube Angle | Effective Seat Tube Angle | Head Tube Length | Head Tube Angle | Effective Top Tube | BB Height | BB Offset | Chainstay Length | Wheelbase | Frame Reach | Frame Stack | Standover Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| All Size | 330 | 72 | 72 | 120 | 70 | 600 | 327 | 12 (Drop) | 385- 397.7 | 1047.2- 1059.9 | 416.7 | 564.27 | 651.9 |
| 140 | 145 | 150 | 155 | 160 | 165 | 170 | 175 | 180 | 185 | 190 | cm | |
| S |
※商品仕様、カラーその他は、予告なく変更される可能性があります
