PURPLE
PURPLE
LIGHT BROWN
LIGHT BROWN
税込価格:¥104,500
FEATURE:| FRAME | AL6 MINIVELO FRAME, 20" |
|---|---|
| FORK | ALLOY RIGID FORK |
| HANDLERBAR | ENTITY ALLOY 640MM BARBORE 31.8MM, BEND: 6DEG |
| STEM | ENTITY SPORT ALLOY EXT:45MM, R/D : 3DEG |
| HEADSET | ZERO STACK(ZS) SEALED BEARING, ZS 44/28.6 , ZS44/30 |
| SADDLE | SELLE ROYAL STEEL RAIL |
| SEATPOST | ENTITY SPORT |
| CRANKSET | ALLOY CRANK SET 48T 170MM |
| BOTTOM BRACKET | BSA THREADED FOR 2-PIECE CRANKSET |
| CHAIN | KMC CHAIN |
| CASSETTE SPROCKET | SHIMANO CS-HG500 10 SPEED 11-34T |
| REAR DERAILLEUR | SHIMANO TIAGRA RD-4700 DIRECT ATTACH |
| SHIFTING LEVER | SHIMANO TIAGRA SL-4700 1x10SPEED RAPID FIRE |
| BRAKE LEVER | TEKTRO HD-M275 HYDRAULIC DISC BRAKE |
| TYRE | VEE SPEEDSTER 20X2.0” |
| WHEELSET | ALLOY DOUBLE WALL FOR 406 TYRE |
| SIZE (CT) | M |
| COLOR | LIGHT BROWN / PURPLE |
| WEIGHT | 10.94 KG |
| A | B | C | D | E | F | G | H | I | J | K | L | M | |
| Size | Seat Tube Length | Seat Tube Angle | Effective Seat Tube Angle | Head Tube Length | Head Tube Angle | Effective Top Tube | BB Height | BB Offset | Chainstay Length | Wheelbase | Frame Reach | Frame Stack | Standover Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 360 | 74.5 | 74.5 | 250 | 70 | 570 | 290 | 35 (DROP) | 400 | 1078.5 | 412.5 | 569.5 | 594 |
| 140 | 145 | 150 | 155 | 160 | 165 | 170 | 175 | 180 | 185 | 190 | cm | |
| M |
※商品仕様、カラーその他は、予告なく変更される可能性があります
